Rich Solar ALPHA 4 | 24V 100Ah LiFePO4 Battery

ALPHA 4 is a 24V 100Ah LiFePO4 battery from Rich Solar exclusively engineered for your RVs, campers, cabins, marine, DIY projects and in general, a reliable power for your off-grid fancy living.

ALPHA 4 features 2560Wh deep cycle battery with a 100Ah nominal capacity that lasts for over 5000+ life cycles. Built to withstand erratic weather conditions, ALPHA 4 boasts of internal heat technology that triggers internal heat when the temperature reaches <5-degree C and automatically cuts off heat once the battery temperature reaches 10-degree C.

A smart battery, one can monitor its operational status via mobile devices in real time with the built-in Bluetooth module.

Specifications:

BATTERY

Cell Type: LiFePO4 Battery

Nominal Voltage: 25.6V

Nominal Capacity: 100Ah

Nominal Energy: 2560Wh

Cycle Life: 5000 cycles

Maximum Expansion (Parallel & Series): 4P4S

BMS

BMS: 100A

Maximum Charging Current: 100A

Maximum Continuous Discharge Current: 100A

Maximum Discharge Current 10 Seconds: 110A

CHARGE

Charge Method: CC/CV

Charge Voltage: 14.4V ± 0.2V

Recommend Charge Current: 50A (0.2C)

TEMPERATURE

Charge Temperature: 32℉ to 131℉ (0℃ to 55℃)

Discharge Temperature: -4℉ to 140℉ (-20℃ to 60℃)

Storage Temperature: 14℉ to 95℉ (-10℃ to 35℃)

SELF-HEATING

External Power Draw: 100W

Internal Heating Starts: < 41℉ (5℃)

Internal Heating Stops: > 50℉ (10℃)

OTHERS

Net Battery Weight: 48.5lb

Dimensions (L*W*H): 20.9 x 8.1 x 8.5in

Housing Material: ABS (Flame Retardant Plastic)

Protection Class: IP65

Warranty: 5 Years

Certifications: UL1973, FCC, UN38.3, ETL

What's in the Box:

1 x ALPHA 4 24V 100Ah LiFePO4 Battery

1 x User Manual

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Security

Product FAQs

Name: Rich Solar ALPHA 4 | 24V 100Ah LiFePO4 Battery
Brand: Rich Solar
SKU: RS-B241S
Price: 759.99 USD
Availability: InStock

What is the total usable energy capacity of the Rich Solar ALPHA 4?

The ALPHA 4 provides 2.56kWh (2560Wh) of usable energy from its 100Ah 25.6V LiFePO4 configuration with 100% depth of discharge.

How does the ALPHA 4 perform in cold weather environments?

The battery features internal heat technology that automatically activates when temperature drops below 5°C and automatically cuts off once the battery reaches 10°C, allowing operation in low-temperature conditions.

How many charge cycles can the ALPHA 4 battery complete before degradation?

The ALPHA 4 is rated for over 5000 life cycles, making it suitable for long-term off-grid applications.

Can I monitor the ALPHA 4 battery status remotely?

Yes, the built-in Bluetooth module enables real-time operational status monitoring via mobile app on your smartphone or tablet.

Is the ALPHA 4 expandable or stackable for higher capacity needs?

The product specifications do not indicate stackable or parallel configuration capability; verify with Rich Solar for expansion options.
